This article mainly aims to discuss a programming pattern used in Kubernetes’s kubectl command — the Visitor pattern (note: in fact, kubectl mainly uses two patterns: Builder and Visitor). Originally, Visitor is an important design pattern in object-oriented programming (see the Wikipedia entry Visitor Pattern). This pattern is a method of separating algorithms from the structure of the objects on which they operate. The practical result of this separation is the ability to add new operations to existing object structures without modifying those structures, which follows the Open/Closed Principle.

This article focuses on how kubectl implements this pattern using a functional approach.

A Simple Example

Let’s begin with a basic example of the Visitor design pattern.

In our code, there’s a function type Visitor, and an interface Shape, which requires the use of a Visitor function as a parameter. Our example object types Circle and Rectangle implement the Shape interface’s accept() method, which is where the Visitor is passed in from the outside.

package main

import (
    "encoding/json"
    "encoding/xml"
    "fmt"
)

type Visitor func(shape Shape)

type Shape interface {
    accept(Visitor)
}

type Circle struct {
    Radius int
}

func (c Circle) accept(v Visitor) {
    v(c)
}

type Rectangle struct {
    Width, Heigh int
}

func (r Rectangle) accept(v Visitor) {
    v(r)
}

Now we implement two Visitors — one for JSON serialization and one for XML serialization:

func JsonVisitor(shape Shape) {
    bytes, err := json.Marshal(shape)
    if err != nil {
        panic(err)
    }
    fmt.Println(string(bytes))
}

func XmlVisitor(shape Shape) {
    bytes, err := xml.Marshal(shape)
    if err != nil {
        panic(err)
    }
    fmt.Println(string(bytes))
}

Here’s the code that uses the Visitor pattern:

func main() {
    c := Circle{10}
    r := Rectangle{100, 200}
    shapes := []Shape{c, r}

    for _, s := range shapes {
        s.accept(JsonVisitor)
        s.accept(XmlVisitor)
    }
}

In fact, the purpose of this code is to decouple the data structures from the algorithms. The Strategy pattern can also achieve this and may look cleaner. However, in some cases, multiple Visitors are used to access different parts of a data structure. In such scenarios, the data structure is somewhat like a database, and each Visitor acts as a small application. kubectl is one such case.

Kubernetes Background

Next, let’s go over some background knowledge:

• Kubernetes abstracts many types of Resources, such as: Pod, ReplicaSet, ConfigMap, Volumes, Namespace, Roles, etc. These various types make up Kubernetes’s data model. (Click Kubernetes Resources Map to see how complex it is.)
• kubectl is a command-line client tool in Kubernetes. Operators use it to manage the cluster. kubectl communicates with the Kubernetes API Server, which in turn talks to each node’s kubelet to control them.
• The main job of kubectl is to process user inputs (CLI arguments, YAML files, etc.), organize them into structured data, and send it to the API Server.
• Related source code is found at: src/k8s.io/cli-runtime/pkg/resource/visitor.go (source link).

kubectl’s code is fairly complex, but its core principle is simple: it uses the Builder pattern to parse command-line input and YAML into Resources, and then uses the Visitor pattern to iterate and process those Resources.

kubectl Implementation

Visitor Pattern Definition

First, kubectl mainly processes a structure called Info. Here’s the related definition:

type VisitorFunc func(*Info, error) error

type Visitor interface {
    Visit(VisitorFunc) error
}

type Info struct {
    Namespace   string
    Name        string
    OtherThings string
}

func (info *Info) Visit(fn VisitorFunc) error {
    return fn(info, nil)
}

We can see:

• A function type VisitorFunc is defined.
• A Visitor interface requires a method Visit(VisitorFunc) error (just like the Shape interface from the earlier example).
• The Info struct implements the Visit() method of the Visitor interface by simply calling the passed-in function.

Let’s Define Several Visitor Types

Name Visitor

This visitor accesses the Name and Namespace fields in the Info struct:

type NameVisitor struct {
    visitor Visitor
}

func (v NameVisitor) Visit(fn VisitorFunc) error {
    return v.visitor.Visit(func(info *Info, err error) error {
        fmt.Println("NameVisitor() before call function")
        err = fn(info, err)
        if err == nil {
            fmt.Printf("==> Name=%s, NameSpace=%s\n", info.Name, info.Namespace)
        }
        fmt.Println("NameVisitor() after call function")
        return err
    })
}

What we see here:

• NameVisitor is a struct that wraps another Visitor — this implies polymorphism.
• Its Visit() method calls the Visit() of the inner Visitor, acting like a decorator.

OtherThings Visitor

This visitor accesses the OtherThings field:

type OtherThingsVisitor struct {
    visitor Visitor
}

func (v OtherThingsVisitor) Visit(fn VisitorFunc) error {
    return v.visitor.Visit(func(info *Info, err error) error {
        fmt.Println("OtherThingsVisitor() before call function")
        err = fn(info, err)
        if err == nil {
            fmt.Printf("==> OtherThings=%s\n", info.OtherThings)
        }
        fmt.Println("OtherThingsVisitor() after call function")
        return err
    })
}

Log Visitor

type LogVisitor struct {
    visitor Visitor
}

func (v LogVisitor) Visit(fn VisitorFunc) error {
    return v.visitor.Visit(func(info *Info, err error) error {
        fmt.Println("LogVisitor() before call function")
        err = fn(info, err)
        fmt.Println("LogVisitor() after call function")
        return err
    })
}

Code that Uses the Visitors

Let’s look at how to use the above code:

func main() {
    info := Info{}
    var v Visitor = &info
    v = LogVisitor{v}
    v = NameVisitor{v}
    v = OtherThingsVisitor{v}

    loadFile := func(info *Info, err error) error {
        info.Name = "Linus"
        info.Namespace = "Linux"
        info.OtherThings = "Talk is cheap, show me the code."
        return nil
    }

    v.Visit(loadFile)
}

What we can observe:

• Visitors are nested one inside another.
• loadFile simulates reading data from a file.
• The final call v.Visit(loadFile) triggers the full chain.

Expected output:

LogVisitor() before call function
NameVisitor() before call function
OtherThingsVisitor() before call function
==> OtherThings=We are running as remote team.
OtherThingsVisitor() after call function
==> Name=Hao Chen, NameSpace=MegaEase
NameVisitor() after call function
LogVisitor() after call function

Effects of the above code:

• Decouples data and processing logic.
• Uses decorator pattern.
• Achieves a pipeline style of processing.

Visitor Decorator

Now let’s refactor the above using the decorator pattern:

type DecoratedVisitor struct {
    visitor    Visitor
    decorators []VisitorFunc
}

func NewDecoratedVisitor(v Visitor, fn ...VisitorFunc) Visitor {
    if len(fn) == 0 {
        return v
    }
    return DecoratedVisitor{v, fn}
}

func (v DecoratedVisitor) Visit(fn VisitorFunc) error {
    return v.visitor.Visit(func(info *Info, err error) error {
        if err != nil {
            return err
        }
        if err := fn(info, nil); err != nil {
            return err
        }
        for i := range v.decorators {
            if err := v.decorators[i](info, nil); err != nil {
                return err
            }
        }
        return nil
    })
}

Explanation:

• DecoratedVisitor stores all VisitorFunc functions.
• NewDecoratedVisitor takes any number of VisitorFunc and constructs the object.
• Visit() loops through and executes each function.

Now the usage becomes:

info := Info{}
var v Visitor = &info
v = NewDecoratedVisitor(v, NameVisitor, OtherVisitor)

v.Visit(LoadFile)

Isn’t that simpler than before?

Note: DecoratedVisitor itself can also be treated as a Visitor.

All of the above patterns and logic are present in kubectl’s source code. If you understand the logic here, you’ll likely be able to read and comprehend the kubectl source code too.
